| محل منبع: | چين |
|---|---|
| نام تجاری: | BOZHONG |
| گواهی: | ISO / TUV / DNV |
| شماره مدل: | 444 |
| مقدار حداقل تعداد سفارش: | قابل توافق |
| قیمت: | negotiable |
| جزئیات بسته بندی: | بسته بندی دریایی یا همانطور که لازم است |
| زمان تحویل: | 3--10 روز |
| شرایط پرداخت: | اعتبارات اسنادی T/T، وسترن یونیون، MoneyGram |
| قابلیت ارائه: | 10000TON / ماه |
| شرح: | لوله/لوله فولادی 444 | مقطع تحصیلی: | 444 |
|---|---|---|---|
| شکل: | گرد، مربع یا در صورت نیاز | قطر خارجی: | 6 تا 720 میلی متر، 1/8 تا 36 اینچ |
| ضخامت دیوار: | 0.89 تا 60 میلی متر | طول: | 1 ~ 14 متر یا سفارشی |
| برجسته: | stainless steel welded tube,stainless steel seamless pipe,stainless steel seamless pipe |
||
Bozhong Group is the professional manufacturer of 400 series stainless steel seamless pipes and Tubes. Stainles steel 400 series pipes are of high hardness and strength compared with 300 series.This Feature determines the 400 series pipe need special technology in the production.Usually the production period of 400 seroes pipe need 30-35 days.
Standard: AISI, ASTM, DIN, EN, GB and JIS ASTM A268
Materials:
400series:
409,409L,410 420,420J1,420J2,...
430,431,444,446,440A,440B,440C...
Production process: cold drawing and precision rolling
Outer diameter: 6 to 720mm, 1/8 to 36 inches
Wall Thickness: 0.89 to 60mm
Length: 1~14 meters or customized
Applications: seawater environment, petrochemical, fertilizer, oil refining, oil and natural gas, light/food, paper pulp and making paper, energy and environmental-protection industry
Packing: plastic polybag, wooden case or bundle
With wide experience and expertise, Bozhong Group is one of the leading 409 410 420 446 ferritic pipe tube manufacturers and suppliers. We have hundreds of high-qualified workers at your service. Please rest assured to get the competitive price 409 410 420 446 ferritic pipe tube for sale with us.
| Type | Grade | Grade | Chemical Component % | ||||||||||
| C | Cr | Ni | Mn | P | S | Mo | Si | Cu | N | Other | |||
| 409 | 3cr12 | ≤0.08 | 10.50-11.75 | ≤0.5 | ≤1.00 | ≤0.045 | ≤0.030 | - | ≤1.00 | - | - | Ti(6C-0.75%) | |
| 409L | 3cr12 | ≤0.03 | 10.50-11.75 | ≤0.5 | ≤1.00 | ≤0.045 | ≤0.030 | - | ≤1.00 | - | - | Ti(6C-0.75%) | |
| 410L | 00Cr12 | ≤0.030 | 11.00-13.00 | 3) | ≤1.00 | ≤0.035 | ≤0.030 | - | ≤1.00 | - | - | - | |
| 430 | 1Cr17 | ≤0.12 | 16.00-18.00 | 3) | ≤1.25 | ≤0.035 | ≤0.030 | - | ≤0.75 | - | - | - | |
| 430F | Y1Cr17 | ≤0.12 | 16.00-18.00 | 3) | ≤1.00 | ≤0.035 | ≥0.15 | 1) | ≤1.00 | - | - | - | |
| 434 | 1Cr17Mo | ≤0.12 | 16.00-18.00 | 3) | ≤1.00 | ≤0.035 | ≤0.030 | 0.75-1.25 | ≤1.00 | - | - | - | |
| 447J1 | 00Cr30Mo2 | ≤0.010 | 28.50-32.00 | - | ≤0.40 | ≤0.035 | ≤0.030 | 1.50-2.50 | ≤0.40 | - | ≤0.015 | - | |
| XM27 | 00Cr27Mo | ≤0.010 | 25.00-27.50 | - | ≤0.40 | ≤0.035 | ≤0.030 | 0.75-1.50 | ≤0.40 | - | ≤0.015 | - | |
| Martensite stainless steel | 403 | 1Cr12 | ≤0.15 | 11.50-13.00 | 3) | ≤1.00 | ≤0.035 | ≤0.030 | - | ≤0.50 | - | - | - |
| 410 | 1Cr13 | ≤0.15 | 11.50-13.50 | 3) | ≤1.00 | ≤0.035 | ≤0.030 | - | ≤1.00 | - | - | - | |
| 405 | 0Cr13 | ≤0.08 | 11.50-13.50 | 3) | ≤1.00 | ≤0.035 | ≤0.030 | - | ≤1.00 | - | - | - | |
| 416 | Y1Cr13 | ≤0.15 | 12.00-14.00 | 3) | ≤1.25 | ≤0.035 | ≥0.15 | 1) | ≤1.00 | - | - | - | |
| 410J1 | 1Cr13Mo | ≤0.08-0.18 | 11.50-14.00 | 3) | ≤1.00 | ≤0.035 | ≤0.030 | 0.30-0.60 | ≤0.60 | - | - | - | |
| 420J1 | 2Cr13 | 0.16-0.25 | 12.00-14.00 | 3) | ≤1.00 | ≤0.035 | ≤0.030 | - | ≤1.00 | - | - | - | |
| 420J2 | 3Cr13 | 0.26-0.35 | 12.00-14.00 | 3) | ≤1.00 | ≤0.035 | ≤0.030 | - | ≤1.00 | - | - | - | |
| 420F | Y3Cr13 | 0.26-0.40 | 12.00-14.00 | 3) | ≤1.25 | ≤0.035 | ≥0.15 | 1) | ≤1.00 | - | - | - | |
| 3Cr13Mo | 0.28-0.35 | 12.00-14.00 | 3) | ≤1.00 | ≤0.035 | ≤0.030 | 0.50-1.00 | ≤0.80 | - | - | - | ||
| 4Cr13 | 0.36-0.45 | 12.00-14.00 | 3) | ≤0.80 | ≤0.035 | ≤0.030 | - | ≤0.60 | - | - | - | ||
| 431 | 1Cr17Ni2 | 0.11-0.17 | 16.00-18.00 | 1.50-2.50 | ≤0.80 | ≤0.035 | ≤0.030 | - | ≤0.80 | - | - | - | |
| 440A | 7Cr17 | 0.60-0.75 | 16.00-18.00 | 3) | ≤1.00 | ≤0.035 | ≤0.030 | 4) | ≤1.00 | - | - | - | |
| 440B | 8Cr17 | 0.75-0.95 | 16.00-18.00 | 3) | ≤1.00 | ≤0.035 | ≤0.030 | 4) | ≤1.00 | - | - | - | |
| 9Cr18 | 0.90-1.00 | 17.00-19.00 | 3) | ≤0.80 | ≤0.035 | ≤0.030 | 4) | ≤0.80 | - | - | - | ||
| 440C | 11Cr17 | 0.95-1.20 | 16.00-18.00 | 3) | ≤1.00 | ≤0.035 | ≤0.030 | 4) | ≤1.00 | - | - | - | |
| 440F | Y11Cr17 | 0.95-1.20 | 16.00-18.00 | 3) | ≤1.25 | ≤0.035 | ≥0.15 | 4) | ≤1.00 | - | - | - | |
| 9Cr18Mo | 0.95-1.10 | 16.00-18.00 | 3) | ≤0.80 | ≤0.035 | ≤0.030 | 0.40-0.70 | ≤0.80 | - | - | - | ||
| 9Cr18MoV | 0.85-0.95 | 17.00-19.00 | 3) | ≤0.80 | ≤0.035 | ≤0.030 | 1.00-1.30 | ≤0.80 | - | - | V0.07-0.12 | ||
